Partitions can be transparent, opaque or decorated.The project for the Hotel Bussola d’Orta in San Giulio (NO) was a partition for the reception room made from around 8 metres of folding glass panels decorated with Tree bronzed finish glass from the Omnidecor line. The central doors are also equipped with handles and when the moveable wall is closed, it acts as a transition between the 2 dining rooms.
|
movable all glass wall Also the Hotel Tartesh in Sardinia chose the Giemme System as an internal partition for its dining room: with 10mm clear tempered float glass for maximum brightness. The folding glass panels can be used without a floor guide rail up to a maximum of 4 panels (or 8 including both sides). The glass, fixtures and accessories can be customized with various finishes to blend in perfectly with the environment. |
|
 Bi-folding decorated glass door |
|
The Giemme System, when installed as a moveable wall partition, ensures a good level of sound insulation. In fact, the 10mm tempered glass has a noise reduction capacity of 33/35 db. The transparent H seals between the individual panels create a single wall which shelters from the weather and external noise. This is excellent if we consider for example a 10cm plank, whose sound absorbency is approximately 41 db or a 20cm wall with a sound absorbency of 48db. |
 |
 Internal partitions with decorated glass |
|
|
|||
 |
Glass doors that fold up to the side, without an entrance door Doors fold up to the mounted side. Available without a floor rail guide up to a maximum of 4 doors. Can be opened internally or externally. |
||
 |
Glass doors with a centrally located entrance door. Also available with a different size entrance door. Also available without a floor guide rail up to a maximum of 4 doors (total of 8, 4 at each side). |
||
 |
 |
||
3D moveable partition wall with centrally located entrance door. Can be folded up to one or both sides. |
3D is a classic moveable partition without an entrance door or handles |
||
|
Glass doors with a centrally opening entrance door Also available without a floor guide rail up to a maximum of 4 doors (4+4 folding up to both sides) |
||
|
|||
 |
Folding up beyond the tight size The top support rail and the floor guide rail can be lengthened to allow you to fold up the doors beyond the tight size. This solution is only available without a floor guide rail. |
||
 |
Hidden folding doors It’s also possible to create niches in which the folding doors can be hidden. |
||
 |
The recessed rail and the best lighting Building spot lights into the ceiling is the best way to emphasize the decorated or transparent Giemme System partition. Also the top support rail can be recessed to create a more aesthetically pleasing product. A good idea is to put LED lights behind frosted glass. The result will create beams of coloured lights that radiate onto the glass. |
 |
|
 |
|||
|
|
Technical Specification The best results can only be achieved with the best technology. GM Morando's products are easy to use thanks to the constant development of new technology. |
|
|
|
Solutions The colour, the glass, the method of folding the glass (external, internal or at one or both sides), doors, locks….decisions to be taken |
|
